Machine weight: 26000
Engine power: 140kw/1800rpm
Compaction width: 2170mm
Weichai WP6G190E331 engine, with excellent performance, high reliability and good fuel economy, is the mainstream configuration power for Chinese construction machinery. Shantui’s patented new vibration wheel has better structure and stability.
| Parameter name | SR26M-3 (Standard version) |
| Performance parameters | |
| Operating weight (Kg) | 26000 |
| Exciting force (KN) | 435/315 |
| Vibration frequency (Hz) | 29/35 |
| Nominal amplitude (mm) | – |
| Ground pressure (KPa) | – |
| Gradeability (%) | – |
| Engine | |
| Engine model | WP6 |
| Rated power/rated speed (kW/rpm) | 140/1800 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 6442*2432*3314 |
| Driving performance | |
| Forward speed (km/h) | 2.8/5.5/9.0 |
| Reversing speed (km/h) | 2.8/5.5/9.0 |
| Chassis System | |
| Wheelbase (mm) | – |
| Tank capacity | |
| Fuel tank (L) | 375 |
| Working device | |
| Compacting width（mm） | 2170 |
